SEUIC (Dongji) / Wearable terminals
AUTOID Ecard: Wearable terminals
AUTOID Ecard is listed in the wearable terminals portfolio for wearable worker and barcode interactions. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: hands-free worker identification, scan and task workflows
- Auto scan |
- Support (automatic light scanning when pulled out)
- power supply
- Non-removable 700mAH lithium-ion rechargeable battery, 500 cycles, capacity greater than 80%, can transmit power values to the host via Bluetooth
- Drop specifications
- 1.2m marble drop, 6 sides and 5 rounds, 30 times
- weight
- 55g
- size
- 100*61*8.7mm (the highest part of the scanning bulge is 8.7mm thick), and the remaining 6.6mm thick
- button
- 2 scan buttons, 1 power button, 1 million times lifespan
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where AUTOID Ecard fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Picking and replenishment
- Worker identification and task prompts
- Inspection and mobile ticketing
Key capabilities
- A wearable terminal entry; host connectivity, wearing position, battery cycle and task UI need validation.
- Portfolio fit: hands-free worker identification, scan and task workflows.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Operating temperature | | -20℃ to +60℃ |
|---|---|
| Storage temperature | -30℃ to +70℃ |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
| Memory | | Scanning parameters can be configured wirelessly, please refer to the product specification for details. |
Data capture
| Auto scan | | Support (automatic light scanning when pulled out) |
|---|
Power and physical
| weight | 55g |
|---|---|
| power supply | Non-removable 700mAH lithium-ion rechargeable battery, 500 cycles, capacity greater than 80%, can transmit power values to the host via Bluetooth |
| button | 2 scan buttons, 1 power button, 1 million times lifespan |
| Interface | | TYPE-C |
Environmental
| humidity | 5% to 95% RH without condensation |
|---|---|
| Drop specifications | 1.2m marble drop, 6 sides and 5 rounds, 30 times |
Other configuration
| size | 100*61*8.7mm (the highest part of the scanning bulge is 8.7mm thick), and the remaining 6.6mm thick |
|---|---|
| Indicator light | | Red and green two-color light, the red light lights up when charging, the green light lights up when charging is completed, and the red light flashes when the battery level is less than 20%. Red and blue two-color light, the scan is successful, the red light flashes once |
| Speakers | | Built-in speaker, 8 ohms 1 watt*1 (only supports scanning beeps), can be turned on or off via Bluetooth control |
| Vibration motor | | Supported, can be turned on or off via Bluetooth control |
| Waterproof and dustproof industrial grade | IP67 |
| Warm reminder | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm straps, wearable hygiene, charging, host pairing and shift handover requirements.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make AUTOID Ecard part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
