SEUIC (Dongji) / Industrial tablets
AUTOID Pad Air 5G OpenHarmony: Industrial tablets
AUTOID Pad Air 5G OpenHarmony is listed in the industrial tablets portfolio for large-screen mobile work and operator guidance. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: large-screen warehouse, field, retail and industrial applications
- CPU
- Zhanrui 7885, eight cores 2.7GHz
- storage
- 8G+256G
- display screen
- 10.1-inch display, capacitive touch, 800nit high-brightness screen · 1920(H)×1200(W)
- Barcode support
- 1D: UPC/EAN, UPC/EAN, Code128, GS1-128, Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, IATA 2 of 5, · Industrial2 of 5, Codabar, MSI, Code11, etc. · 2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, etc.
- power supply
- Non-removable 10140mAh typical lithium-ion rechargeable battery
- drop rating
- 1.2 meters
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where AUTOID Pad Air 5G OpenHarmony fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Warehouse and production dashboards
- Field inspection and work instructions
- Vehicle, cart or workstation deployments
Key capabilities
- A tablet platform for industrial applications; operating system, mounting, ports and environmental scope require confirmation.
- Portfolio fit: large-screen warehouse, field, retail and industrial applications.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| CPU | Zhanrui 7885, eight cores 2.7GHz |
|---|---|
| operating system | OpenHarmony 5.0 (optional Starlight Unicorn) |
| storage | 8G+256G |
| User storage extension | Micro SD Card, supports up to 512GB |
| display screen | 10.1-inch display, capacitive touch, 800nit high-brightness screen · 1920(H)×1200(W) |
| storage temperature | -20℃ to +60℃ (including battery) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
| positioning system | Single Beidou positioning |
Data capture
| sensor | Gravity sensor, light sensor, electronic compass, gyroscope |
|---|---|
| Barcode support | 1D: UPC/EAN, UPC/EAN, Code128, GS1-128, Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, IATA 2 of 5, · Industrial2 of 5, Codabar, MSI, Code11, etc. · 2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, etc. |
| front camera | Camera function: fixed focus · pixels: 5 million |
| rear camera | Photography function: phase focus · pixels: 13 million · supports flash + fill light |
Connectivity
| SIM interface | Nano SIM card*1 |
|---|---|
| Interface/communication | Waterproof Type C USB interface; supports OTG; supports fast charging |
| Wireless LAN WIFI protocol | IEEE 802.11a/b/g/n/ac |
| Wireless LAN WIFI frequency range | Depends on the country (region), 2.4GHz is 2.412GHz-2.472 GHz; 5GHz is 5.170GHz-5.825GHz |
Power and physical
| power supply | Non-removable 10140mAh typical lithium-ion rechargeable battery |
|---|---|
| Weight (including standard battery) | 725g (including battery) |
Environmental
| working temperature | -20℃ to +50℃ |
|---|---|
| humidity | 5% to 95% RH without condensation |
| drop rating | 1.2 meters |
Other configuration
| keyboard | Volume +, - keys, power on/off key |
|---|---|
| Notification method | Sound, vibrator, LED light indication |
| Audio | Built-in dual speakers (4Ω2W) |
| size | 258(H)×173(W)×11.6(T)mm |
| Waterproof and dustproof industrial grade | IP65 |
| Optical resolution | 1280 x 1080 pixes |
| field of view | Horizontal 39.6° Vertical 33.8° |
| Laser safety level | Class II |
| Rotate view | 360° |
| Up and down tilt angle | ±60° |
| Shift angle of view left and right | ±55° |
| depth of field | Code128 20mil 12cm~60cm |
| frequency | B1(1.561GHz) |
| Readable and writable tags | Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards); supports NFC protocol |
| Working frequency | 13.56MHz |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Scope mounts, docks, vehicle power, protective equipment and keyboard or scanner integration with the final use case.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make AUTOID Pad Air 5G OpenHarmony part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
