SEUIC (Dongji) / Industrial tablets
AUTOID Pad Air Windows: Industrial tablets
AUTOID Pad Air Windows is listed in the industrial tablets portfolio for large-screen mobile work and operator guidance. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: large-screen warehouse, field, retail and industrial applications
- Display
- 0.1-inch full-viewing LCD display, 1920x1200, 400 nits
- Scan |
- X3 1D/2D advanced laser scanning engine
- Power |
- User-non-removable 5070mAh Li-ion rechargeable battery
- Sealing level
- IP65 sealing (including battery)
- Interface/Communication |
- TYPE-C interface, supports host charging, supports USB3.0 (downwardly compatible with USB2.0), supports DisplayPort, and supports headphones
- weight
- 690g/24.34 ounces (weight will vary depending on configuration)
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where AUTOID Pad Air Windows fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Warehouse and production dashboards
- Field inspection and work instructions
- Vehicle, cart or workstation deployments
Key capabilities
- A tablet platform for industrial applications; operating system, mounting, ports and environmental scope require confirmation.
- Portfolio fit: large-screen warehouse, field, retail and industrial applications.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | 0.1-inch full-viewing LCD display, 1920x1200, 400 nits |
|---|---|
| Touch screen | | capacitive touch |
| CPU | | Intel Core M3-8100Y, 2 cores and 4 threads, 1.1GHz, maximum turbo frequency 3.4GHz/Intel UHD615, base frequency 300MHz, maximum dynamic frequency 900MHz |
| operating system | | Windows 10 loT Enterprise Edition 64-bit (can be upgraded to Windows 11IOT) |
| Memory | | 8GB (LPDDR31867MHz)/128GB (SSD can be customized to 256GB) |
| Operating temperature | | -10°C to 50°C/14°F to 122°F |
| Storage temperature | | -20°C to 60°C/-4°F to 140°F (batteries not included) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
Data capture
| interactive sensor technology | Acceleration sensor, light sensor, distance sensor, electronic compass, gyroscope |
|---|---|
| Scan | | X3 1D/2D advanced laser scanning engine |
Connectivity
| SIM card | | Nano SIM*1 |
|---|---|
| Interface/Communication | | TYPE-C interface, supports host charging, supports USB3.0 (downwardly compatible with USB2.0), supports DisplayPort, and supports headphones |
| GPS | GPS+GLONASS+Beidou, support AGPS |
| WIFI | | IEEE 802.11a/b/g/n/ac (2.4G/5G dual-band WIFI) 2X2 MIMO |
Power and physical
| weight | 690g/24.34 ounces (weight will vary depending on configuration) |
|---|---|
| Power | | User-non-removable 5070mAh Li-ion rechargeable battery |
| button | | 3 buttons (power, volume +, -) |
Environmental
| Humidity | | 5% to 95% RH non-condensing state |
|---|---|
| Sealing level | IP65 sealing (including battery) |
| Drop specifications | | Withstands a 3.94 ft (1.2 m) drop to marble when terminated only |
Other configuration
| size | 10.16 inches (L) x 6.81 inches (W) x 0.46 inches (H) 258mm (L) x 173mm (W) x 10.8mm (H) |
|---|---|
| expansion slot | User-accessible Micro SD Card, supports SDXC, supports up to 256GB |
| Internet connection | | WLAN, WPAN, WWAN4G (selected) |
| Notification | | Alert sound; multi-color LED; vibration (tactile feedback) |
| Keyboard | | On-screen keyboard |
| Audio | | Built-in stereo speakers, 4022W*2; built-in dual microphones, supports TypeC digital headsets |
| Image acquisition | | Camera front 2 million pixels; rear 8 million pixels (auto focus) |
| Standard accessories | PD fast charging adapter x1, dual TYPEC data cable x1, hand strap x1 |
| Optional accessories | The whole machine is a single multifunctional stand-mounted charger, silicone protective cover, tempered film, and strap. |
| Kind tips | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Scope mounts, docks, vehicle power, protective equipment and keyboard or scanner integration with the final use case.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make AUTOID Pad Air Windows part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
