SEUIC (Dongji) / Handheld RFID readers
AUTOID UM3: Handheld RFID readers
AUTOID UM3 is listed in the handheld rfid readers portfolio for mobile RFID inventory and item identification. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: mobile UHF RFID inventory and asset workflows
- CPU
- X1500
- Reading speed
- Up to 800 times/second
- Output power
- Adjustable from 1dBm to 33dBm, 1.0dBm step
- Protection level
- IP65
- Communication interface
- Type C
- weight
- 500g
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where AUTOID UM3 fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Cycle counts and stock checks
- Asset audits and tool tracking
- Returns, receiving and exception handling
Key capabilities
- A handheld RFID reader entry; region-specific frequency, antenna, read behavior and host integration require testing.
- Portfolio fit: mobile UHF RFID inventory and asset workflows.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| CPU | X1500 |
|---|---|
| Operating frequency | | 860Mhz – 960Mhz (can be adjusted according to the requirements of different countries or regions) |
| Offline storage | 100,000 pictures@Maximum 128bits EPC |
Data capture
| Reading speed | Up to 800 times/second |
|---|---|
| Reading distance | >10m @impinj H47 (the actual distance is affected by the tag and environment) |
Connectivity
| Communication interface | Type C |
|---|
Power and physical
| Output power | Adjustable from 1dBm to 33dBm, 1.0dBm step |
|---|---|
| battery capacity | 6400mAh (Typical value) Note: Rated capacity 6200 mAh |
| weight | 500g |
Environmental
| Environmental characteristics | Working temperature: -20℃ to +46℃, storage temperature: -40℃ to +60℃ |
|---|---|
| Protection level | IP65 |
Other configuration
| tag protocol | EPC C1 GEN2 / ISO18000-6C |
|---|---|
| antenna | 4dbi circular polarization antenna |
| writing distance | Writing distance 0-3m (affected by label and environment) |
| status indication | Power indicator, working status indicator light, buzzer |
| Audio | built-in speaker |
| Compatible device size | Equipment width 60-80mm |
| working hours | 8-12 hours |
| size | 169(H)×90(W)×145(T)mm |
| Kind tips | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm sled or integrated antenna, trigger, battery, carry method and application SDK requirements.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make AUTOID UM3 part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
