SEUIC (Dongji) / Handheld RFID readers
AUTOID UTouch 2-30: Handheld RFID readers
AUTOID UTouch 2-30 is listed in the handheld rfid readers portfolio for mobile RFID inventory and item identification. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: mobile UHF RFID inventory and asset workflows
- CPU
- Octa core 2.0GHz
- storage
- 6GB+64GB (optional 8GB+128GB)
- display screen
- 5.5-inch display, capacitive touch · 1440(H)×720(W)
- 2D Image Scan Engine Optical Resolution
- 1280 x 1080 pixes
- Weight (including standard battery)
- 715g (weight varies with different configurations)
- drop rating
- 1.5 meters
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where AUTOID UTouch 2-30 fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Cycle counts and stock checks
- Asset audits and tool tracking
- Returns, receiving and exception handling
Key capabilities
- A handheld RFID reader entry; region-specific frequency, antenna, read behavior and host integration require testing.
- Portfolio fit: mobile UHF RFID inventory and asset workflows.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| display screen | 5.5-inch display, capacitive touch · 1440(H)×720(W) |
|---|---|
| CPU | Octa core 2.0GHz |
| operating system | Android 14 |
| storage | 6GB+64GB (optional 8GB+128GB) |
| User storage extension | Micro SD Card, compatible with up to 256GB |
| storage temperature | -40℃ to +60℃ (battery included) · -40℃ to +70℃ (battery not included) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
| 2D image scanning engine image frame rate | 60fps |
| GPS geographical location information collection and positioning system | GPS+GLONASS+Beidou, support AGPS |
Data capture
| sensor | G-sensor, light sensor, distance sensor, electronic compass, gyroscope |
|---|---|
| 2D Image Scan Engine Optical Resolution | 1280 x 1080 pixes |
| 2D image scanning engine tilted up and down viewing angle | Deviation from normal angle ±60° |
| Two-dimensional image scanning engine shifts the viewing angle left and right | Deviation from normal angle ±55° |
| 2D Image Scan Engine Laser Safety Rating | Class II |
| 2D image scan engine supports symbols | 1D: UPC/EAN, UPC/EAN, Code128, GS1-128, Code 39, · Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI, Code11, etc. · 2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, etc. |
| 2D image scanning engine lighting and projection | Warm color light, laser projection |
| 2D Image Scan Engine Minimum Print Contrast | 20% |
| Rear camera image capture maximum resolution | 4224*3136 |
| Rear camera image acquisition pixels | 13 million |
| Rear camera image collection and photography function | PDAF phase focusing |
| Rear camera image capture flash + fill light | support |
| Front camera image collection maximum resolution | 2592*1944 |
| Front camera image acquisition pixels | 5 million |
| Front camera image collection and photo taking function | fixed focus |
Connectivity
| Interface/communication | Waterproof Type C USB interface, supports USB2.0 HighSpeed, supports OTG |
|---|
Power and physical
| Weight (including standard battery) | 715g (weight varies with different configurations) |
|---|---|
| power supply | ≧11700mAh (host 5000mAH + handle 6700mAh replaceable) · Bottom Type C USB interface, supports QC3.0 fast charging, intelligently identifies PC and charger |
Environmental
| working temperature | -20℃ to +50℃ |
|---|---|
| humidity | 5% to 95% RH without condensation |
| drop rating | 1.5 meters |
Other configuration
| size | 159(H)*78(W)*133(T)mm |
|---|---|
| keyboard | Power + volume (+, -) + UHF + SCAN + custom + handle buttons |
| Notification method | Sound, vibrator, LED light indication |
| Audio | Built-in single speaker, built-in dual microphones (with noise reduction function) |
| card slot | SIM+TF · PSAM*1 (micro medium card) (optional) |
| Waterproof and dustproof industrial grade | IP67 |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm sled or integrated antenna, trigger, battery, carry method and application SDK requirements.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
