SEUIC (Dongji) / Barcode scanners
HS200C: Barcode scanners
HS200C is listed in the barcode scanners portfolio for reliable barcode capture at a fixed or operator-held station. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: countertop, workstation and industrial barcode capture
- Readable barcode types
- 1D: Code39, Code128, Code93, Codabar, UPC/EAN, I2of5, GS1 128, etc. · 2D: PDF417, MicroPDF417, Aztec, Data Matrix, QR, Micro QR, etc.
- Protection level |
- IP54
- Communication interface
- RS232, USB keyboard, USB COM
- weight
- 148g±3g
- image sensor
- 1280x1024 CMOS sensor
- Lens classification
- High-density HD lens; standard SR lens
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where HS200C fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Point-of-sale and service counters
- Production and quality stations
- Parcel, shipping and workstation capture
Key capabilities
- A scanner entry for 1D, 2D or application-specific capture; symbology, distance, lighting and host interface require testing.
- Portfolio fit: countertop, workstation and industrial barcode capture.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| frame rate | | Up to 60 frames/second |
|---|---|
| Operating temperature | | 0℃ to 50℃ |
| storage temperature | -20℃ to 70℃ |
| Electrostatic discharge (ESD) | | ±15kV air discharge, ±8kV contact discharge |
Data capture
| image sensor | 1280x1024 CMOS sensor |
|---|---|
| Readable barcode types | 1D: Code39, Code128, Code93, Codabar, UPC/EAN, I2of5, GS1 128, etc. · 2D: PDF417, MicroPDF417, Aztec, Data Matrix, QR, Micro QR, etc. |
| Reading direction | Elevation angle ±60°; oblique angle ±55° |
| Recognition accuracy | | 1D code: 3mil 2D code: 5mil |
Connectivity
| Communication interface | RS232, USB keyboard, USB COM |
|---|
Power and physical
| weight | 148g±3g |
|---|
Environmental
| Humidity | | 5% to 95% RH non-condensation |
|---|---|
| Protection level | | IP54 |
| Drop Rating | | Can withstand 50 drops from 1.8m in the air |
| Roll Specs | | Can withstand 2,000 0.5m tumble impacts |
Other configuration
| Lens classification | High-density HD lens; standard SR lens |
|---|---|
| lighting source | White LED |
| sight | Dot LED |
| Read depth of field (typical) | | 3.3mil Code128: 4cm~11cm (HD high-density version) · 5mil Code128: 3cm~14cm (HD high-density version) 3cm~28cm (SR standard version) · 10mil Code128: 4cm~15cm (HD high-density version) 1cm~44cm (SR standard version) · 13mil EAN 13: 2cm~18cm (HD high-density version) )1cm~43cm (SR standard version) · 5mil DM/QR: 4cm~8cm (HD high density version) · 6.6mil DM/QR: 3cm~10cm (HD high density version) · 10mil DM/QR: 1cm~14cm (HD high density version) 3.5cm~25cm (SR standard version) · 20mil DM/QR: 1cm~21cm (HD high density version) 2cm~42cm (SR standard version) |
| Size | | 166.2 * 105.5 * 68.5mm |
| Light Level | | 0 to 100,000Lux |
| Shell material | High strength engineering plastics |
| Certification | | CE、FCC、RoHS |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Validate stands, cables, mounting, host protocol, scan angle and difficult-code performance in the target environment.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make HS200C part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
