SEUIC (Dongji) / Barcode scanners
HS305DP: Barcode scanners
HS305DP is listed in the barcode scanners portfolio for reliable barcode capture at a fixed or operator-held station. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: countertop, workstation and industrial barcode capture
- Readable barcode types
- 1D: Code39, Code128, Code93, Codabar, UPC/EAN, I2of5, GS1 128, etc. · 2D: PDF417, MicroPDF417, Aztec, Data Matrix, QR, Micro QR, etc.
- Protection level
- IP54
- Communication interface
- RS232, USB keyboard, USB COM
- weight
- 162g±3g
- image sensor
- CMOS sensor with global shutter 1280x1080
- Lens classification
- DPM lens (horizontal 40.2°, vertical 46.9°)
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where HS305DP fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Point-of-sale and service counters
- Production and quality stations
- Parcel, shipping and workstation capture
Key capabilities
- A scanner entry for 1D, 2D or application-specific capture; symbology, distance, lighting and host interface require testing.
- Portfolio fit: countertop, workstation and industrial barcode capture.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Frame rate | Up to 60 frames/second |
|---|---|
| storage temperature | -20℃ to 70℃ |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV contact discharge |
Data capture
| image sensor | CMOS sensor with global shutter 1280x1080 |
|---|---|
| Readable barcode types | 1D: Code39, Code128, Code93, Codabar, UPC/EAN, I2of5, GS1 128, etc. · 2D: PDF417, MicroPDF417, Aztec, Data Matrix, QR, Micro QR, etc. |
| Reading direction | Elevation angle ±60°; oblique angle ±55° |
| Recognition accuracy | 1D code: 3mil · 2D code: 5mil |
| Reading depth of field (typical) | Barcode type: 3.3mil Code128, depth of field 3.5cm~6.5cm, 0~6cm · Barcode type: 5mil Code128, depth of field 1.5cm~18cm, 0~9.1cm · Barcode type: 10mil Code128, depth of field 0.5cm~28cm, 0~13.3cm · Barcode type: 13mil EAN 13. Depth of field 1cm~26.5cm, 1cm~9.1cm · Barcode type: 5mil DM/QR, depth of field 3.7cm~7.2cm, 0~6cm · Barcode type: 10mil DM/QR, depth of field 1.9cm~15.9cm, 0~9.1cm · Barcode type: 20mil DM/QR, depth of field 0~33.5cm, 0~17.1cm |
Connectivity
| Communication interface | RS232, USB keyboard, USB COM |
|---|
Power and physical
| weight | 162g±3g |
|---|
Environmental
| working temperature | 0℃ to 50℃ |
|---|---|
| humidity | 5% to 95% RH without condensation |
| Protection level | IP54 |
| drop rating | Can withstand 50 drops from 1.8m in the air |
| rolling specifications | Can withstand 2,000 0.5m tumble impacts |
Other configuration
| Lens classification | DPM lens (horizontal 40.2°, vertical 46.9°) |
|---|---|
| lighting source | Intelligent adjustable diffuse light source red white blue |
| sight | Laser cross with aiming frame |
| size | 166.2(H)× 105.5(W)×68.5(T) mm |
| light level | 0 to 100,000Lux |
| Shell material | High strength engineering plastics |
| Certification | CE、FCC、RoHS |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
