SEUIC (Dongji) / Handheld RFID readers
UHF Autonomous 1: Handheld RFID readers
UHF Autonomous 1 is listed in the handheld rfid readers portfolio for mobile RFID inventory and item identification. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: mobile UHF RFID inventory and asset workflows
- CPU
- Octa core 2.7GHz
- Display |
- 6-inch display, capacitive touch, 1440(H)×720(W)
- 2D Image Scan Engine | Optical Resolution
- 1280 x 1080 pixes
- Power |
- 8350mAh (host 5000mAH + handle 3350mAh replaceable), handle optional 6700mAh; Type C USB interface at the bottom, supports PD3.0 fast charging protocol, intelligently identifies PC and charger
- Drop specifications
- 1.5 meters
- Interface/Communication |
- Waterproof Type C USB interface, supports USB2.0 HighSpeed, supports OTG
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where UHF Autonomous 1 fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Cycle counts and stock checks
- Asset audits and tool tracking
- Returns, receiving and exception handling
Key capabilities
- A handheld RFID reader entry; region-specific frequency, antenna, read behavior and host integration require testing.
- Portfolio fit: mobile UHF RFID inventory and asset workflows.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | | 6-inch display, capacitive touch, 1440(H)×720(W) |
|---|---|
| CPU | Octa core 2.7GHz |
| operating system | Starlight Unicorn |
| User storage extension | Micro SD Card, compatible with up to 256GB |
| Storage temperature | -40℃ to +70℃ (battery not included) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
| 2D Image Scan Engine | Image Frame Rate | 60fps |
| GPS positioning system | GPS+GLONASS+Beidou, support AGPS |
Data capture
| sensor | G-sensor, light sensor, distance sensor, electronic compass, gyroscope |
|---|---|
| 2D Image Scan Engine | Optical Resolution | 1280 x 1080 pixes |
| 2D image scanning engine | Up and down oblique viewing angle | Deviation from normal angle ±60° |
| 2D image scanning engine | Left and right offset viewing angle | Deviation from normal angle ±55° |
| 2D Image Scan Engine | Laser Safety Level | Class II |
| 2D Image Scan Engine | Supported Symbols | 1D: UPC/EAN, UPC/EAN, Code128, GS1-128, Code 39, · Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, IATA 2 of 5, Industrial2 of 5, Codabar, MSI, Code11, etc. · 2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, etc. |
| 2D image scanning engine | lighting, projection | Warm color light, laser projection |
| Rear camera maximum resolution | 4208*3120 |
| Rear camera pixels | 13 million |
| Rear camera camera function | PDAF phase focusing |
| Rear camera flash + fill light | support |
| Front camera maximum resolution | 3264*2448 |
| Front camera pixels | 8 million |
| Front camera photo function | fixed focus |
Connectivity
| Interface/Communication | | Waterproof Type C USB interface, supports USB2.0 HighSpeed, supports OTG |
|---|---|
| GPS frequency | GPS: L1; Beidou: B1; GLONASS: L1 |
Power and physical
| Power | | 8350mAh (host 5000mAH + handle 3350mAh replaceable), handle optional 6700mAh; Type C USB interface at the bottom, supports PD3.0 fast charging protocol, intelligently identifies PC and charger |
|---|---|
| Weight (with standard battery) | | 680g (including battery, varies according to different configurations) |
Environmental
| working temperature | -20℃ to +50℃ |
|---|---|
| humidity | 5% to 95% RH without condensation |
| Drop specifications | 1.5 meters |
Other configuration
| size | 190(H) x 92(W) x 138(T) mm |
|---|---|
| Keyboard | | Power + volume (+, -) + UHF + SCAN + custom + handle buttons |
| Audio | | Built-in single speaker, built-in microphone |
| Notification method | Sound, vibrator, LED light indication |
| store | 4GB+64GB (optional 8GB+128GB) |
| card slot | SIM (Nano-simx1) + TF, PSAMx2 (micro medium card) (optional) |
| Waterproof and dustproof industrial grade | IP67 |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm sled or integrated antenna, trigger, battery, carry method and application SDK requirements.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make UHF Autonomous 1 part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
