UROVO / Payment terminals
Q200: Payment terminals
UROVO provides professional POS Android terminals & other mobile computers device solutions equipped with efficient custom enterprise enabled software.
Best fit: retail payment, assisted checkout and unattended transaction workflows
- CPU
- 32bit RISC processor
- Barcode Reading
- Rapidly read industry-leading 1D/2D barcode on paper, PC, and smartphone screen · Rapidly read QR code, electrical tag, coupon, and color barcode on screen of mobile device. · Default enable：EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、Code39、Code93、CodaBar、QR Code、PDF417、DataMatrix · Default disable：Interleaved 2 of 5、Industrial 25、Matrix 2 of 5、Code11、MSI Plessey 、RSS-14、RSS-Limited、RSS-Expanded
- Dimensions
- 130mmLx108mmWx105mmH
- OS
- Compatible with Windows, Android, and Linux operation system
- Camera
- 640(horizontal)X 480(vertical) CMOS，30fps
- Field of view
- Roll 360°，skew±45°，pitch±45°
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where Q200 fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Retail checkout and assisted payment
- Service-counter transactions
- Payment pilots with a defined acquiring environment
Key capabilities
- A payment-device entry for an acquiring and application review; certification, country variant and payment stack must be confirmed.
- Portfolio fit: retail payment, assisted checkout and unattended transaction workflows.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| CPU | 32bit RISC processor |
|---|---|
| OS | Compatible with Windows, Android, and Linux operation system |
Data capture
| Camera | 640(horizontal)X 480(vertical) CMOS，30fps |
|---|---|
| Barcode Reading | Rapidly read industry-leading 1D/2D barcode on paper, PC, and smartphone screen · Rapidly read QR code, electrical tag, coupon, and color barcode on screen of mobile device. · Default enable：EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、Code39、Code93、CodaBar、QR Code、PDF417、DataMatrix · Default disable：Interleaved 2 of 5、Industrial 25、Matrix 2 of 5、Code11、MSI Plessey 、RSS-14、RSS-Limited、RSS-Expanded |
Power and physical
| Dimensions | 130mmLx108mmWx105mmH |
|---|---|
| Weight | 270g |
| Interface | Support USB-HID or USB virtual serial port USB HID-KBW(Default) |
Environmental
| Environmental | Working Temperature: -20℃ ~ 60℃ · Storage temperature: -40℃ ~ 70℃ · Working Humidity: 5%RH~95%RH（non condensing） · Shockwave: 5~200Hz，10Grms，3axes，1.5Hr · Drip Resistance: 5 ft./1.5 m drops on concrete |
|---|
Other configuration
| Field of view | Roll 360°，skew±45°，pitch±45° |
|---|---|
| Decode Ranges | EAN13：0~110mm(13mil) · Code128：0 ~ 150mm(20mil) · Code39：0~35mm(5mil) · Payment QR code：0 ~ 250mm (5”screen) |
| Cable Length | 5 ft./1.5 m |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm payment peripherals, connectivity, power, security controls and integration ownership before a quote.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make Q200 part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
