SEUIC (Dongji) / Keypad mobile terminals
AUTOID 3P: Keypad mobile terminals
AUTOID 3P is listed in the keypad mobile terminals portfolio for fast operator-led data capture with physical input. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: high-throughput, glove-friendly and scan-intensive operations
- Display
- 4-inch color full HD (480*800), 400nit
- scanning
- Optional: · X3P(SR) 1D/2D scan engine · X3P(HD) 1D/2D scan engine · X3P(MR) 1D/2D scan engine
- Power |
- User-removable 5200mAh (20.02Wh) lithium-ion rechargeable battery; fuel gauge monitors battery status in real time
- Sealing level |
- IP65 sealing (including battery)
- Interface/communication
- Waterproof Type C USB interface; supports OTG
- weight
- 265g/9.35oz (including battery)
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where AUTOID 3P fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Distribution and sorting
- Manufacturing and line-side work
- Cold-chain or glove-use workflows
Key capabilities
- A keypad mobile terminal entry for repetitive scan work; key layout, scan engine, display and battery variant require review.
- Portfolio fit: high-throughput, glove-friendly and scan-intensive operations.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | 4-inch color full HD (480*800), 400nit |
|---|---|
| touch screen | Capacitive touch, supports glove touch/wet hand operation/double-click to wake |
| CPU | | MTK 8-core, 2.0GHz |
| operating system | | Android 12.0 |
| Memory | | 2GB RAM/32GB Flash; 4GB RAM/64GB Flash |
| Operating temperature | | -20℃ to 55℃/-4℉ to 131℉ |
| Storage temperature | | -40℃ to 70℃/-40℉ to 158℉ (battery not included) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
Data capture
| Interactive Sensor Technology | | Light sensor (optional), distance sensor (optional), gyroscope (optional), electronic compass (optional) |
|---|---|
| scanning | Optional: · X3P(SR) 1D/2D scan engine · X3P(HD) 1D/2D scan engine · X3P(MR) 1D/2D scan engine |
| Camera | | Rear 13 million pixels (auto focus); · LED flash can generate balanced white light; supports flashlight mode |
| Near Field Communication (NFC) | | Optional |
Connectivity
| SIM card | | Nano SIM*1 |
|---|---|
| Interface/communication | Waterproof Type C USB interface; supports OTG |
| GPS | GPS, Beidou, GLONASS/Galilieo three-in-one, supports A-GPS |
Power and physical
| weight | 265g/9.35oz (including battery) |
|---|---|
| Power | | User-removable 5200mAh (20.02Wh) lithium-ion rechargeable battery; fuel gauge monitors battery status in real time |
| button | Two dedicated scan buttons |
Environmental
| Humidity | | 5% to 95% RH without condensation |
|---|---|
| Sealing level | | IP65 sealing (including battery) |
| Roll Specs | | Withstands 1,000 drops from 1.6 feet/0.5 meters at room temperature without protective case |
| Drop specifications | Terminal only, withstands a 6 ft./1.8 m drop to marble. |
Other configuration
| size | 6.26" long x 2.61" wide x 0.74" high · 159mm long x 66.3mm wide x 18.9mm high |
|---|---|
| expansion slot | User-accessible Micro SD Card, supports up to 256GB |
| Internet connection | | WWAN、WLAN |
| Notification | | Alert sound; multi-color LED; vibration (tactile feedback) |
| keyboard | 25-key numeric keypad with FN key; supports on-screen keyboard |
| Audio | Built-in single speaker (2W); microphone; supports TYPE C headphones |
| radio frequency band | GSM: Quad Band (900/1800Mhz) · TD-SCDMA: B34, B39; · WCDMA: B1, B5, B8; · CDMA 1x /EVDO: BC0; · TDD-LTE: B34, B38, B39, B40, B41; · FDD-LTE: B1, B3, B5, B8; |
| Kind tips | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Scope pistol grip, cold-environment protection, batteries, cradles and operator carry method for the shift.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make AUTOID 3P part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
