SEUIC (Dongji) / Keypad mobile terminals
AUTOID 10: Keypad mobile terminals
AUTOID 10 is listed in the keypad mobile terminals portfolio for fast operator-led data capture with physical input. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: high-throughput, glove-friendly and scan-intensive operations
- operating system
- Android 14
- Display
- 4.0-inch color full HD (800*480) brightness 400nit
- scanning
- X3P(SR) 1D/2D advanced laser scanning engine · X3P(HD) 1D/2D advanced laser scanning engine · X3P(MR) 1D/2D advanced laser scanning engine · S9 1D/2D advanced laser scanning engine
- Power |
- User-removable 5360mAh (20.63Wh) lithium-ion rechargeable battery; hot-swappable battery supported
- Sealing level |
- IP67 sealing level (including battery)
- Interface/communication
- Type C USB interface; supports OTG (does not support display)
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where AUTOID 10 fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Distribution and sorting
- Manufacturing and line-side work
- Cold-chain or glove-use workflows
Key capabilities
- A keypad mobile terminal entry for repetitive scan work; key layout, scan engine, display and battery variant require review.
- Portfolio fit: high-throughput, glove-friendly and scan-intensive operations.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | 4.0-inch color full HD (800*480) brightness 400nit |
|---|---|
| touch screen | Capacitive touch, supports glove touch/wet hand operation/double-click to wake up |
| CPU | | Qualcomm 6115 octa-core, 2.0GHz |
| operating system | Android 14 |
| Memory | | 4 GB memory/64 GB storage (LPDDR4X+EMMC 5.1) |
| Operating temperature | | -20℃ to 50℃ / -4℉ to 122℉ |
| Storage temperature | -40℃ to 70℃/-40℉ to 158℉ (battery not included) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
Data capture
| Interactive Sensor Technology | | Gravity sensor, light sensor, distance sensor, electronic compass, gyroscope |
|---|---|
| scanning | X3P(SR) 1D/2D advanced laser scanning engine · X3P(HD) 1D/2D advanced laser scanning engine · X3P(MR) 1D/2D advanced laser scanning engine · S9 1D/2D advanced laser scanning engine |
| Camera | Front 5 million pixels; rear 13 million pixels (auto focus) · LED flash can generate balanced white light; supports flashlight mode |
| Near Field Communication (NFC) | | Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards) |
Connectivity
| SIM card | Nano SIM*2 |
|---|---|
| Interface/communication | Type C USB interface; supports OTG (does not support display) |
| GPS | GPS, Beidou, GLONASS three-in-one, supports A-GPS; · Dual-frequency GPS (L1+L5) |
| wireless connection | IEEE802.11a/b/g/n/ac (2.4G/5G dual-band WIFI6-Ready) |
Power and physical
| weight | 280g/9.88oz (including battery, varies according to different configurations) |
|---|---|
| Power | | User-removable 5360mAh (20.63Wh) lithium-ion rechargeable battery; hot-swappable battery supported |
| button | 27 keys in total: 23 front numeric keys and 1 front scan key; 1 side PPT key; 2 side scan keys |
Environmental
| humidity | 5% to 95% RH non-condensing state |
|---|---|
| Sealing level | | IP67 sealing level (including battery) |
| Roll Specs | | Withstands 1,000 drops from 1.6 feet / 0.5 meters at room temperature without protective case |
| Drop specifications | Withstands a 6-foot (1.8-meter) drop to marble when terminated only |
Other configuration
| size | 6.34" (L) x 2.64" (W) x 0.77" (H) · 161mm L x 67mm W x 19.5mm H |
|---|---|
| expansion slot | User-accessible Micro SD Card, supports up to 256GB |
| Internet connection | | WWAN 4G、WLAN |
| Notification | | Alert sound; multi-color LED; vibration (tactile feedback) |
| keyboard | 23 front digital buttons, crystal buttons |
| Audio | Built-in single speaker (1.5W); single microphone; supports TYPE C headphones |
| radio frequency band | GSM：850，900，1800； · TD-SCDMA：B34，B39； · WCDMA：B1，B5，B8； · TDD-LTE：B34，B38，B39，B40，B41（200Mhz）； · FDD-LTE：B1，B3，B5，B7，B8，B20，B28； · CA（DL）B1+B3,B39+B41 |
| data rate | 2.4GHz: 802.11b/g/n, 2.412GHz-2.472GHz, up to 150Mbps; · 5GHz: 802.11a/g/n/ac, 5.17GHz-5.825GHz, up to 433Mbps; |
| working channel | CH1-CH13, CH34-CH165; specific support depends on the country (region) |
| Security and Encryption | | OPEN, WEP, WPA2-PSK(TKIP+AES), TLS, TTLS(MS-CHAP), TTLS(MS-CHAP V2), TTLS (CHAP), TTLSMD5, TTLS-PAP, PEAP-TLS, PEAP (MS-CHAPV2), AES, etc. |
| Kind tips | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Scope pistol grip, cold-environment protection, batteries, cradles and operator carry method for the shift.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
