SEUIC (Dongji) / Touch mobile terminals
CRUISE2 5G OpenHarmony: Touch mobile terminals
CRUISE2 5G OpenHarmony is listed in the touch mobile terminals portfolio for touch-first mobile data capture. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: touch-first warehouse, retail, logistics and field applications
- CPU
- Zhanrui 7885, eight cores 2.7GHz
- storage
- 8G+128G
- display screen
- 6-inch display, capacitive touch · 2160(H)×1080(W)
- Barcode support
- 1D: UPC/EAN, UPC/EAN, Code128, GS1-128, Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, IATA 2 of 5, · Industrial2 of 5, Codabar, MSI, Code11, etc. · 2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, etc.
- power supply
- Removable 5000mAh lithium-ion rechargeable battery (including backup battery)
- drop rating
- 1.5 meters
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where CRUISE2 5G OpenHarmony fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Warehouse and logistics applications
- Retail inventory and store operations
- Field inspection and service
Key capabilities
- A full-touch mobile terminal entry; scan engine, network, OS and battery options require model-level confirmation.
- Portfolio fit: touch-first warehouse, retail, logistics and field applications.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| CPU | Zhanrui 7885, eight cores 2.7GHz |
|---|---|
| operating system | OpenHarmony 5.0 (optional Starlight Unicorn) |
| storage | 8G+128G |
| User storage extension | Micro SD Card, supports up to 512GB |
| display screen | 6-inch display, capacitive touch · 2160(H)×1080(W) |
| storage temperature | -40℃ to +60℃ (including battery) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
| positioning system | Beidou |
Data capture
| sensor | Gravity sensor, light sensor, distance sensor, electronic compass, gyroscope |
|---|---|
| Barcode support | 1D: UPC/EAN, UPC/EAN, Code128, GS1-128, Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, IATA 2 of 5, · Industrial2 of 5, Codabar, MSI, Code11, etc. · 2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, etc. |
| front camera | Camera function: fixed focus · pixels: 8 million |
| rear camera | Camera function: Phase focus · Pixels: 16 million |
Connectivity
| SIM interface | Nano SIM card*1 (supports 5G) |
|---|---|
| Interface/communication | Waterproof Type C USB interface; supports USB3.0; supports OTG; supports fast charging |
| Wireless LAN WIFI protocol | IEEE 802.11 a/b/g/n/ac |
Power and physical
| power supply | Removable 5000mAh lithium-ion rechargeable battery (including backup battery) |
|---|---|
| Weight (including standard battery) | 279g (including battery) |
Environmental
| working temperature | -20℃ to +50℃ |
|---|---|
| humidity | 5% to 95% RH non-condensation state |
| drop rating | 1.5 meters |
Other configuration
| keyboard | Volume +, - keys, power on/off key, 2 side scan keys, function keys |
|---|---|
| Notification method | Sound, vibrator, LED light indication |
| Audio | Built-in single speaker (2W), built-in dual microphones |
| size | 161(H)×77(W)×13.9(T)mm |
| Waterproof and dustproof industrial grade | IP68 |
| Impact resistance | 1000 rounds of 0.5 meter rolling (equivalent to 2000 impacts) |
| Optical resolution | 1280 x 1080 pixes |
| field of view | Horizontal 39.6° Vertical 33.8° |
| Laser safety level | Class II |
| Rotate view | 360° |
| Up and down tilt angle | ±60° |
| Shift angle of view left and right | ±55° |
| depth of field | Code128 20mil 12cm~60cm |
| frequency | B1(1.561GHz) |
| Readable and writable tags | Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards); supports NFC protocol |
| Working frequency | 13.56MHz |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm scan handle, spare battery, cradle, protective case and MDM or application enrollment needs.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make CRUISE2 5G OpenHarmony part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
