SEUIC (Dongji) / Touch mobile terminals
CRUISE2: Touch mobile terminals
CRUISE2 is listed in the touch mobile terminals portfolio for touch-first mobile data capture. RuggedLayer can confirm the exact variant and project fit before quotation.
Best fit: touch-first warehouse, retail, logistics and field applications
- CPU
- Octa-core 2.0 GHz
- Memory
- 4GB memory/64GB flash memory; compatible with 6GB memory/64GB flash memory, 8GB memory/128GB flash memory
- Display
- 5.5-inch display, capacitive touch, supports wet hand mode, glove mode, 720*1440 resolution
- 2D image scanning engine (optional)
- Please refer to product specifications for details
- power supply
- Removable 5000mAh lithium-ion rechargeable battery; compatible with removable 6000mAh lithium-ion rechargeable battery (optional); 40mAh lithium-ion battery (backup battery, optional)
- Drop specifications
- Withstands a 1.5 m (4.92 ft) drop to tile on concrete when terminated only
Final SKU, regional configuration and commercial terms are confirmed before quotation.
Selection context
Where CRUISE2 fits
Use the workload and operating conditions to decide whether this platform belongs in the shortlist.
Best for
- Warehouse and logistics applications
- Retail inventory and store operations
- Field inspection and service
Key capabilities
- A full-touch mobile terminal entry; scan engine, network, OS and battery options require model-level confirmation.
- Portfolio fit: touch-first warehouse, retail, logistics and field applications.
- Exact OS, interfaces, accessories and regional configuration require confirmation.
Product configuration
Key specifications
Review the available model configuration, then confirm the exact combination required for your application and target market.
Platform
| Display | 5.5-inch display, capacitive touch, supports wet hand mode, glove mode, 720*1440 resolution |
|---|---|
| CPU | Octa-core 2.0 GHz |
| operating system | Android 11 and Android 14 optional |
| Memory | 4GB memory/64GB flash memory; compatible with 6GB memory/64GB flash memory, 8GB memory/128GB flash memory |
| Storage temperature | -40℃ to +70℃ (battery not included) |
| Electrostatic discharge (ESD) | ±15kV air discharge, ±8kV direct discharge |
Data capture
| interactive sensor technology | Gravity sensor, light sensor, distance sensor, electronic compass, gyroscope |
|---|---|
| Near field communication (NFC) | Supports ISO15693, ISO14443A/B (without encryption protocol), ISO14443A tags with encryption protocol (Mifare one S50, S70 and compatible cards); supports NFC protocol |
| 2D image scanning engine (optional) | Please refer to product specifications for details |
Connectivity
| Interface/communication | Waterproof Type-C USB interface; supports USB2.0 HighSpeed; supports Type-C headphones; supports OTG; supports fast charging; Nano SIM card/TF card, choose two from three |
|---|---|
| SIM card | Choose 2 from 3 card holders, support dual SIM card dual standby, Nano SIM card |
| GPS | GPS+GLONASS+Beidou, support AGPS |
| Wireless LAN | IEEE 802.11a/b/g/n/ac (2.4G/5G dual-band WIFI) |
Power and physical
| weight | 255±5g (5000mAh model, including battery); · 279±5g (6000mAh model, including battery) |
|---|---|
| power supply | Removable 5000mAh lithium-ion rechargeable battery; compatible with removable 6000mAh lithium-ion rechargeable battery (optional); 40mAh lithium-ion battery (backup battery, optional) |
| button | Volume up/down buttons; power button; two dedicated scan buttons; programmable button for push-to-talk or other purposes |
Environmental
| working temperature | -20℃ to +55℃ |
|---|---|
| humidity | 5% to 95% RH without condensation |
| Drop specifications | Withstands a 1.5 m (4.92 ft) drop to tile on concrete when terminated only |
| Sealing level | IP68 sealing level (including battery) |
| rolling specifications | At room temperature without a protective cover, it can withstand 1,000 drops from a height of 0.5 meters. |
Other configuration
| size | 156.6mm (length) × 76mm (width) × 13.9mm (height) (5000mAh battery model); · 156.6mm (length) × 76mm (width) × 16.4mm (height) (6000mAh battery model) |
|---|---|
| Audio | Built-in bottom-side single speaker and built-in dual microphones (with noise reduction function) |
| Notification method | Alert sound; vibration (tactile feedback); multi-color LED light indication |
| fingerprint | Support fingerprint function |
| expansion slot | User-accessible Micro SD Card, supports up to 256GB |
| keyboard | On-screen keyboard |
| expansion slot | Maximum compatible with 128GB (TF card) |
| Image acquisition | Front camera 5 million pixels, rear camera 13 million pixels |
| radio frequency band | GSM：Qual Band(850/900/1800/1900Mhz) · TD-SCDMA：Band34，Band39 · WCDMA：Band1，Band2，Band5，Band8 · CDMA1x /EVDO ：BC0 · TDD-LTE：Band34，Band38，Band39，Band40，Band41 · FDD-LTE：Band1，Band3，Band5，Band7，Band8，Band20，Band28 |
| Kind tips | For current product information and project support, contact RuggedLayer. |
Configurations vary by model revision and market. RuggedLayer confirms the selected SKU, accessories and applicable certifications in the quotation.
Deployment planning
Configure the complete system
A device choice is only useful when software, operator behavior, power and regional constraints are included in the same decision.
Deployment considerations
- Confirm the exact model variant, software image, interfaces and supported accessories before ordering.
- Validate the workflow, environment, network, power and operator interaction on the target configuration.
- Confirm country scope, certifications, frequency bands and commercial availability in the quotation.
Accessories and configuration
- Confirm scan handle, spare battery, cradle, protective case and MDM or application enrollment needs.
Before you order
Validate the exact configuration with RuggedLayer.
Send us the workflow, target country, software constraints and estimated volume. We will help confirm the right variant, test scope and commercial next step before you commit to a deployment.
- 01
Share the target application, workflow, country and expected deployment volume with RuggedLayer.
- 02
Test the exact configuration with the intended host system, scan or capture method and device-management policy.
- 03
Approve the final variant, accessory package and commercial scope before placing the purchase order.
Buy, validate or customize through RuggedLayer
Make CRUISE2 part of a deployment plan.
Request a sample, quote, application validation or customization discussion directly with our team. The model is carried into the project intake so the conversation starts with useful context.
